Window Screening
General Introduction of Window Screening:
Wire Materials of Window Screening: Stainless steel wire, galvanized iron wire, aluminum wire, fiberglass, etc.
Uses: Window screening is widely used in hotels and buildings to prevent insects and bugs from entering.
General sizes: 14mesh, 16mesh, 18mesh, etc.General wire diameter: BWG31 or BWG 32.
| specification | Application | |||
| Mesh | Diameter | Size | ||
| Gal. iron wire netting | 10x10 | BWG31 BWG32 BWG33 BWG34 |
3'x100' 4'x100' 1x25M 1.2x30M 1.5x25M |
Electric galvanized after weaving. White or light-blue |
| 14x14 | ||||
| 16x16 | ||||
| 18x18 | ||||
| 18x14 | ||||
| 22x22 | ||||
| 24x24 | ||||
| Enameled iron wire netting | Same as above | Green or dark green | ||
| Aluminum iron wire netting | Same as above | Silver | ||
| Aluminum wire netting | Same as above | Material: Al-Mg alloy or pure aluminum | ||
| Fiber glass wire netting | 12x12 | BWG31 BWG32 |
3'x100' 4'x100' 1x25M 1.2x25M |
All kinds of color |
| 14x14 | ||||
| 16x16 | ||||
| 16x14 | ||||
| Plastic wire netting | 12x12 | Same as above | Mesh 12,14,16: hinged weave. Mesh 18,22,24: plain weave White , blue, green, etc. |
|
| 14x14 | ||||
| 16x16 | ||||
| 18x18 | ||||
| 18x14 | ||||
| 20x20 | ||||
| Stainless steel wire netting | 14x14 SWG38 16x16 SWG37 18x18 SWG36 18x14 SWG35 20x20 SWG34 |
3'x100' 4'x100' 1x25M 1.2x25M |
Material:304,316,316L | |
| PVC wire netting | 12x 12 | BWG31 BWG32 | Same as above | Fit in with petroleum, pipeline, package |
If you need to consult the price, please contact the business department by e-mail:
Thai Hua will service for you !
E-mail: thaihuawmc@gmail.com mikezhao568@gmail.com info@wiremeshmetal.org
Tel: +66-2-8091803 Mobile: 092-528-6412, 091-495-0700
E-mail: thaihuawmc@gmail.com mikezhao568@gmail.com info@wiremeshmetal.org
Tel: +66-2-8091803 Mobile: 092-528-6412, 091-495-0700
When you contact us, please provide your detail requirements. That will help us give you a valid quotation.
